Statistics of station Nettetal-Kaldenkirchen (BLUE)

Here you can find statistics of the TOA lightning detection station Nettetal-Kaldenkirchen (BLUE).

  • Firmware: 0.0
  • Controller: 19.4
  • Amplifier: H1 / E1
  • Antenna 1+2: Ferrite rod, length=200mm, diameter=1mm, shielded
  • Website: www.wilfried-monika.de
  • Comment: System BLUE mit Ferrite-Antennen lg=200mm, d=10mm (Abgeschirmt)

General statistics of the last hour

  • Station active: yes
  • Last update: 1.0 minutes ago
  • Last detected stroke: 2024-11-21 23:23:57
  • Strokes: 20
  • Signals: 5,643
  • Locating ratio: 0.4%
  • Stroke ratio: 9.5% (Map)
  • Strokes station min participants: 0 (0.0%)

GPS

Some information about the GPS receiver, which is used for receiving the exact time an position. If known, the antenna bearings are also displayed (red, green).

  • Mean coordinates: 51.318065° / 6.202034° (±5.9m)
  • Last time without GPS: 2024-10-09 16:50:34

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Nettetal-Kaldenkirchen (BLUE) and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Nettetal-Kaldenkirchen (BLUE) and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
